- Ultra Wash & Dual Convection Ultra Dry
- Loading Flexibility
- Status Center
- Steam + Sani
- Customizable Hardware Options
- Built-In WiFi Dishwasher
- Adjustable Upper Rack
- Upper Rack Fold-Down Tines
- Lower Rack Fold-Down Tines
- Wash Zones
- 4 Bottle Wash Jets
- Built-In Third Rack
- Smart Water Leak Detector
- Flush Installation
- Extra Large Capacity
- 39 dBA Dishwasher
Specifications
Dimensions
Width23.75"Height34"Depth24"
Finish: White
MPN: CDT875P4NW2
Product Details:
style
Built-In Top Controlpower connection
Optional cord kit (GPFCORD - WX09X70910, WX09X70911)control type
Top ControlsCap Touch Controls12 Touchpadsoverall height
34.0 inoverall width
23.75 inoverall depth
24.0 insabbath mode
Sabbath Modenumber of cycles
5dispenser
Rinse Aid with Indicator and AdjustmentElectronic Low Rinse Aid Sensorhandle
Café(TM)handle color
Brushed Bronzenet weight
124.0 lbinstallation
Side Installation or Top Installation IncludedFlush Cabinet InstallationBuilt-Up Floor Capablecategory
KITCHEN->DISHWASHERSnumber of place settings
Up to 16exterior style
Traditionaldishwasher options
Wash Zone Upper OnlyWash Zone Lower OnlyStart/ResetSabbath ModePresoak + Sanitize (Certified to NSF Standard 184)Normal DryLock ControlsHi-Temp WashHeated Dry OffDual Convection Ultra DryDelay Start 1-12 Hr.Bottle Washrack features
Full Extension Slides - UpperBall-Tipped TinesAdjustable Upper Rack3-Piece Silverware Basket with Cell Covers2 Utility Shelves with Stem Safe and Chop-stick slots - Upperracking material
Nylonfloor protection
Leak Defense with Active Flood Protect - Leak Pan with Sensorrack color
Black Pearlracking system
Full 3rd rackcutlery tray
One piece removable 3rd rackshowroom power mode
Yesleveling system
3 Point Levelingwash system
800 Series3-Leveldishwasher control features
Multi function displayLast Cycle MemoryCycle Countdown with LCD Status Center on doorAudible End-of-Cycle Signaldishwasher drying features
Ultra/Normal/OffFan Assist DryDual Convection Ultra Drywifi connect
Built-Inwater filtration system
100% Filtration with Hard Food Disposer and Removable Filterlower rack
Ball-Tip Tines1/2 fixed tines, 1/2 fold down tinesdishwasher cycles
PotsNormalExpressChinaAutotub type
Tall Tubadditional protection
Leak Defense with Active Flood ProtectActive Flood Protectupper rack
Premium Height AdjustableFixed tines with Bottle JetsChop stick slotsBall-Tip Tines2 Stem Safe Shelves1/2 fixed tines, 1/2 fold down tines1 Rack handlelatch
Pull with Handlewash system features
Variable Speed Dual Pumps and MotorsSide JetsReversing Quad Blade Lower Wash ArmQuad Blade Middle Wash ArmHidden HeaterHard Food Disposer with removable filterDrain PumpDeep Clean Silverware JetsBottle Jets (4)Automatic Temperature ControlAutomatic HotStart90+ Spray Jet Wash Systemsensor
Clean Sensorwash arms
Middle - Quad BladeLower- Reversing Quad BladeJets - Variable PressureDeep Clean Silverware JetsBottle Jets3 Wash Levelsnumber of options
10tub and door liner
Stainless Steeloptional kits
CXADTH1PMSS Brushed StainlessCXADTH1PMCU Brushed CopperCXADTH1PMBT Brushed Blackdoor appearance
Full-length flat doorhandle design
Customizabledoor style
Long Door with Top Controlscolor appearance
Matte Whitequiet package
39 dBAmotor type
Variable Speeddoor insulation
MasticInsulationquiet features
Tub Collar TrimSealed Toe KickQuiet Water Valveouter wrap
Full-wrap BlanketBitumenvolts/hertz/amps
120V; 60Hz; 10.2Acalrod heater watts
1200/400labor warranty
Limited 1-year entire appliancewarranty notes
See written warranty for full detailsparts warranty
Limited 1-year entire appliancecabinet width
24.0 inoverall depth with handle
27.4 inheight w/ legs retracted - minimum height
33.375 inheight w/legs extended - maximum height
34.625 in
UPC: 84691843498
