With our XXL dishwasher are there no longer any issues to get those large, tricky items cleaned. In addition with our different run modes such as Eco, Night, Speed and Intensive mode you will get the perfect result every time.
Construction
Welded stainless steel container
Exterior float - detects water leakage on the base
Stand by water protection
Anti-block drain pump
8 Steel™ Construction
Hidden heater
SCS+ - Super Cleaning System+™
Number of spray arms: 3
Number of spray zones: 8
Cutlery Power Zone - extra dishwashing power for the cutlery basket
Use and flexibility
16 place settings
Number of baskets: 3
Top tray: Easy height adjustment; Divisible and removable baskets in top rack; With rack for knives and utensils; With rack for bowls and cups; With telescopic rails; Handle
Upper basket type: Premium
Guide rails with ball bearings for upper basket
Lower basket type: Premium
Tight mesh base in the baskets
Removable cutlery basket for easy unloading
Required inlet water pressure: 0,03-1 MPa
Interaction & control
Display Type: LCD display
Memory program
Number of programs: 11
Number of options: 8
Delayed start: 1-24 hours
Time remaining indicator: Yes
Cycle end indication: Displayed with sound and light
Programs
11 programs: Normal wash; ECO wash; Hygiene wash; Time program; Plastic wash; Rinse and hold; Sanitation wash; Upper half; Lower half; Crystal glass; Self-cleaning
Variable start delay up to 24 hours
Normal mode
Time Set
Green mode
Speed mode
Night mode
Intensive mode
Extra Dry
High temperature
Normal mode
Design & integration
From front adjustable door spring
From front adjustable rear foot
Velcro strips
Trim kit
Multi fit outlet hose
Simplified installation with integrated anti-siphon
Depth (incl. wall spacing): 22 1/16" (560 mm)
Height setting: 1 15/16" (50 mm)
Possible adjustment of kick plate: 30-94/0
Safety & Maintenance
Aqua Safe™
Kid Safe™ - lockable controls
Rinse-aid indication: Notification in display
Specifications
max. temperature of inflow water :
140 Fnoise level :
44 dB(A)reference program :
1estimated annual energy consumption :
235 kWhenergy consumption/cycle :
1 kWhestimated annual water consumption :
687 US Galwater consumption/cycle :
3 US Galconsumption in off mode :
0.49 Wconsumption in standby mode :
0.49 Wconnection rating :
1300 Wvoltage (v) :
120 Vnumber of phases :
1current :
15 Afrequency :
60 Hzrequired inlet water pressure :
0,03-1 MPanet weight :
107 lbswidth :
24" (609 mm)height :
33 13/16" (859 mm)depth :
22" (559 mm)maximum product height :
35 13/16" (909 mm)cord length :
47 1/4" (1200 mm)depth with door open :
48 3/4" (1238 mm)length of inflow hose :
64 3/16" (1630 mm)length of outflow hose :
90 9/16" (2300 mm)packaging width :
25 3/16" (640 mm)packaging height :
36 5/8" (930 mm)packaging depth :
26 3/4" (680 mm)total weight of packaged product :
115 lbscode :
734120ean code :
3838782328619product_brand
ASKOsku
ASK:DFI663XXL
