About this Product
Elica 18"W / 84"H Tri-Zone Built-In Wine Cooler with a generous 255L capacity and space for up to 68 bottles is crafted for true connoisseurs. Featuring fully integrated panel-ready installation, it blends seamlessly into your kitchen or bar with timeless elegance. Experience the precision of three independently controlled temperature zones—each ranging from 41°F (5°C) to 68°F (20°C)—powered by individual evaporators for optimal preservation. Interior air circulation, a charcoal filter, and Low-E, double-layer UV-resistant glass ensure your collection is safeguarded against external elements while maintaining perfect humidity and temperature balance.
Documents
Highlights
Seamless 3004 Stainless Steel with white plastic interior | Single Panel Ready Door | Zero Clearance Articulating | Hettich Hinges | Tempered Transparent Gray Argon Filled Dual Pane Glass | Electronic Touch Control with white LED Readout | 3 Independent Evaporators | 14 Full-Extension Beechwood Shelves | Strip LED with color options (White, Blue, Amber) | 68 750ml Bottles Capacity | R600a Refrigerant | 43 dBA | Demo Mode | Open Door Alarm | ECO Mode | Air Fan Circulating
Specifications
| Installation | Built-In | Size | Full Size | Bottles | 68 |
| Hinge | Right | Temperature Zones | 3 | Number of Racks | 14 |
| Temperature Settings | 3 Zones (each 41°F (5°C) - 68°F (20°C) | Series Name | Dolomite | Manufacturer Color | Panel Ready |
| Color | Panel Ready | Type | Cellar | Reversible Door | Y |
| Glass Door | Y | Digital Temperature Display | Y | Interior Light | Y |
| Included | ECJKCXX Column Joining Kit | Width | 45.09 cm | Height | 212.25 cm |
| Depth (Without Handle) | 59.21 cm | Weight | 125 kg | Sabbath/Star-K | Y |
|
Technologies Elica Perfect Climate (EPC) | Vibration Dampening System (VDS)
| |||||
|
Optional 18" Stainless Steel Panel Kit: EPNKC18SS (3/4" deep) | Pro Handle Stainless Steel Kit: EPHKCSS | Tubular Handle Stainless Steel Kit: ETHKCSS | Column Joining Kit: ECJKCXX | Water Filter: ERWFX | Water Filter Cover: ERWFC
| |||||
|
Information 120V, 60Hz @ max 1.4 Amp | Plug Type: NEMA 5-15 P plug
| |||||
|
Additional Dimensions Power Cord Length: 91" (2.3 mts.) | Cut Out Dimensions: 18" W x 25" D x 84" H
| |||||
|
Warranty Two (2) Years Parts & In-Home Labor | Earn an additional One (1) Year of Parts & In-Home Labor by registering
| |||||
Accessories
• Pro Handle Stainless Steel Kit: EPHKCSS
• Tubular Handle Stainless Steel Kit: ETHKCSS
• Column Joining Kit: ECJKCXX
• Water Filter: ERWFX
• Water Filter Cover: ERWFC
Specifications
Installation
Built-In
Size
Full Size
Bottles
68
Hinge
Right
Temperature Zones
3
Number of Racks
14
Temperature Settings
3 Zones (each 41°F (5°C) - 68°F (20°C)
Series Name
Dolomite
Manufacturer Color
Panel Ready
Color
Panel Ready
Type
Cellar
Reversible Door
Y
Glass Door
Y
Digital Temperature Display
Y
Interior Light
Y
Included
ECJKCXX Column Joining Kit
Width
45.09 cm
Height
212.25 cm
Depth (Without Handle)
59.21 cm
Weight
125 kg
Weight
147 kg
Sabbath/Star-K
Y
Additional Information
Seamless 3004 Stainless Steel with white plastic interior | Single Panel Ready Door | Zero Clearance Articulating | Hettich Hinges | Tempered Transparent Gray Argon Filled Dual Pane Glass | Electronic Touch Control with white LED Readout | 3 Independent Evaporators | 14 Full-Extension Beechwood Shelves | Strip LED with color options (White, Blue, Amber) | 68 750ml Bottles Capacity | R600a Refrigerant | 43 dBA | Demo Mode | Open Door Alarm | ECO Mode | Air Fan Circulating
Technologies
Elica Perfect Climate (EPC) | Vibration Dampening System (VDS)
Optional
18" Stainless Steel Panel Kit: EPNKC18SS (3/4" deep) | Pro Handle Stainless Steel Kit: EPHKCSS | Tubular Handle Stainless Steel Kit: ETHKCSS | Column Joining Kit: ECJKCXX | Water Filter: ERWFX | Water Filter Cover: ERWFC
Information
120V, 60Hz @ max 1.4 Amp | Plug Type: NEMA 5-15 P plug
Additional Dimensions
Power Cord Length: 91" (2.3 mts.) | Cut Out Dimensions: 18" W x 25" D x 84" H
Warranty
Two (2) Years Parts & In-Home Labor | Earn an additional One (1) Year of Parts & In-Home Labor by registering
