About this Product
Let nothing stand in your way with Dual Level LED lighting and a five-speed blower offering CFMs from 450-1,200 - meeting local standards without compromising power or design. Dishwasher-safe stainless steel baffle filters make removing smoke and odors easily, while filter clean reminders after 30-hours of use for optimal performance. Wi-Fi enabled, this ingenious hood allows you to sync with the cooktop for automatic fan and burner coordination. Use the ThinQ® App for air movement control, LED operation, and hood management.
Features
- DUAL LEVEL LED LIGHTING — Dual-level LED lighting illuminates the cooking surface with a brilliant glow. The LED lights are energy-efficient and have a long life.
- EASY-TO-CLEAN BAFFLE FILTERS — Effectively remove smoke and odors with the dishwasher safe, stainless steel baffle filters. After 60-hours of use, the filter clean reminder will activate, ensuring filters are always performing at their best.
- WI-FI ENABLED FOR CONNECTIVITY — Connect the hood and cooktop for automatic communication with each other so the fans and burners are synchronized. Utilize the ThinQ® App to monitor and control air movement, operate the LED lights and turn the hood on and off.
- VMAX™ TECHNOLOGY (VARIABLE MAXIMUM CFM) - 290 - 1200 CFM — The hood provides a wide range of maximum CFMs from 390 through 1200 CFM to meet local requirements, without having to compromise power or design.
Documents
Highlights
Remote Operations | Internal Blower (Included): 450–1,200 CFM, 3.5–9 Sones | Variable Max. CFM Set at 590: 350-590 CFM, 3.3-6 Sones, 4 Speeds | Variable Max. CFM Set at 390: 350-390 CFM, 3.3-4 Sones, 3 Speeds | Electronic Touch Controls | Auto Delay-Off | Dual-Level Lighting | Lighting Type: LED | Dishwasher Safe Filters: 3 Baffle
Specifications
| Weight | 26.99 kg | Depth | 48.9 cm | Height | 30.48 cm |
| Width | 117.79 cm | Class Width | 48" | Additional Dimensions | Mounting Height Above 36" High: Cooktop / Range 26" Min. – 36" Max. |
| Warranty | Limited 3 Years Parts and Labor | Ducting Information | 10" Round | Wi-Fi | Y |
| Speeds | 5 Speeds | Style | Custom Insert | Manufacturer Color | Stainless Steel |
| Color | Stainless Steel | Installation | Built-In | Blower Included | Y |
| Airflow | 1200 CFM | ||||
|
Technologies Wi-Fi Enabled for ThinQ® Control with iPhone / Android App | VMAX™ Technology
| |||||
|
Information 120 V | 60 Hz | 7 A
| |||||
Specifications
Weight
26.99 kg
Depth
48.9 cm
Height
30.48 cm
Width
117.79 cm
Class Width
48"
Warranty
Limited 3 Years Parts and Labor
Ducting Information
10" Round
Wi-Fi
Y
Speeds
5 Speeds
Style
Custom Insert
Manufacturer Color
Stainless Steel
Color
Stainless Steel
Built-In
Blower Included
Y
Airflow
1200 CFM
Weight
32.7 kg
Additional Dimensions
Mounting Height Above 36" High: Cooktop / Range 26" Min. – 36" Max.
Additional Information
Remote Operations | Internal Blower (Included): 450–1,200 CFM, 3.5–9 Sones | Variable Max. CFM Set at 590: 350-590 CFM, 3.3-6 Sones, 4 Speeds | Variable Max. CFM Set at 390: 350-390 CFM, 3.3-4 Sones, 3 Speeds | Electronic Touch Controls | Auto Delay-Off | Dual-Level Lighting | Lighting Type: LED | Dishwasher Safe Filters: 3 Baffle
Technologies
Wi-Fi Enabled for ThinQ® Control with iPhone / Android App | VMAX™ Technology
Information
120 V | 60 Hz | 7 A
