About this Product
The sealed burner gas range offers updated styling and even more exceptional features. The best can always be better. The Pro Sealed Burner System delivers precision control of 15,000 BTUs. And inside the oven, the combination of a 30,000 BTU u-shaped burner and GourmetGlo™ infrared broiler provide unrivaled power.
Features
- DELICIOUS DETAILED — Sculpted polished chrome bezels, stainless steel knobs, and a fully integrated color control panel bring new clarity and cohesion to the Viking 5 Series Range, refining its presence while honoring its iconic heritage.
- GOURMET-GLO™ GAS INFRARED BROILER — Lock in all the savory juices of even the thickest porterhouse with the intense heat of the restaurant-quality Gourmet-Glo™ Infrared Broiler. Intense heat from broiler sears meats and fish locking in juices.
- PROFLOW™ CONVECTION BAFFLE — Bake breads and cakes to lofty perfection with the incredibly even heat circulation of the ProFlo™ Convection Baffle system. Each ProFlow™ Baffle has been engineered specifically for each oven cavity to maximize even cooking.
- PORCELAINIZED COOKING SURFACE — Keep spills in one place with the raised edges of our exclusive one-piece tooled porcelainized cooking surface. Raised edges around perimeter seal top to completely contain spills. Porcelanized for easy cleaning, durability and long lasting finish.
- VARISIMMER™ SETTING — The VariSimmer™ Setting on ALL burners provides gentle, even simmering at precisely low cooking temperatures.
- SURESPARK™ IGNITION SYSTEM — The exclusive SureSpark™ Ignition System ensures automatic ignition/re-ignition should the burners extinguish any time while cooking.
Documents
Highlights
Exclusive VSH™ (VariSimmer-to-high) Pro sealed burner system | All other burners rated at 15,000 BTU | Exclusive VariSimmer™ setting for all burners | All burners equipped with SureSpark™ ignition system for consistent and reliable ignition | Automatic re-ignition; burners light at any knob position and re-light if extinguished, even on the lowest setting | Stainless steel knobs and round bezels included as standard | Exclusive combination of single 30,000 BTU U-shaped burner and infrared broiler with SureSpark™ ignition system | Gourmet-Glo™ infrared broiler provides intense searing heat for broiling applications | Large-capacity oven with six rack positions | 36" model accommodates a full-size commercial sheet pan | All convection modes use the ProFlow™ convection air baffle for balanced airflow and even heat distribution | Exclusive Gentle Close™ door allows slow and quiet closing | Convection fan switch conveniently located on the control panel | Two halogen oven lights for excellent visibility throughout the oven cavity
Specifications
| Burners/Elements Output | 6X: 15,000 BTU | Burners/Elements | 6 | Burners | Sealed |
| Capacity (cu. ft.) | 5.1 cu. ft. | Number of Ovens | Single | Depth (Without Handles) | 71.2 cm |
| Width | 91.1 cm | Weight | 178.26 kg | Class Width | 36" |
| Height | 91.1 cm | Oven Light | Y | Convection | Y |
| Fuel Type | Natural Gas | Color | Stainless Steel | Series Name | 5 Series |
| Manufacturer Color | Stainless Steel with Polished Chrome Trim | Installation Type | Freestanding | UPC# | 800284100362 |
|
Programs Natural Airflow Bake | Convection Bake | Infrared Broil | Convection Infrared Broil | Convection Dehydrate | Convection Defrost
| |||||
|
Information 120 VAC / 60 Hz | 4 ft (121.9 cm) power cord | 3-wire cord with grounded 3-prong plug attached to product | 1.5 amp
| |||||
|
Additional Dimensions Overall Width: 35-7/8" (91.1 cm) | Overall Height (from bottom): | Base height to top of side trim: 35-7/8" (91.1 cm) minimum to 37" (94 cm) maximum | Legs adjustment: 1-1/8" (2.9 cm) | Additions to base height: | Island trim: +1" (2.5 cm) | Backguard: +8" (15.2 cm) | High shelf: +23-1/2" (59.7 cm) | Overall Depth from rear: | To end of side panel: 24-5/16" (61.8 cm) | To front of door: 25-3/4" (65.4 cm) | To end of door handle: 28-11/16" (72.9 cm)
| |||||
|
Technologies VSH™ (VariSimmer-to-high) Pro | VariSimmer™ Setting | Gourmet-Glo™ Gas Infrared Broiler | ProFlow™ Convection Air Baffle | SureSpark™ Ignition System
| |||||
|
Appliance Care Exclusive one-piece tooled and porcelainized cooking surface for easy cleanup | Removable burner caps for quick cleaning | Heavy-duty porcelainized cast-iron removable grates provide continuous front-to-rear and left-to-right cooking surface for easy movement of large pots
| |||||
|
Warranty 2-year full warranty – complete product | 90-day full warranty – cosmetic parts such as glass, painted items, and decorative items | 5-year limited warranty – gas burners
| |||||
|
Optional BG8536SS – 8"H backguard for 36" range | HS24536SS – high shelf for 36" range | P24CSTSS – countertop side trim (2 pieces) | P36CRTSS – countertop rear trim for 36" range | P36CBF4SS – curb base and custom curb base front for 36" range | LPKPDR01 – LP/Propane conversion kit
| |||||
Accessories
• HS24536SS – high shelf for 36" range
• P24CSTSS – countertop side trim (2 pieces)
• P36CRTSS – countertop rear trim for 36" range
• P36CBF4SS – curb base and custom curb base front for 36" range
• LPKPDR01 – LP/Propane conversion kit
Specifications
Burners/Elements Output
6X: 15,000 BTU
Burners/Elements
6
Burners
Sealed
Capacity (cu. ft.)
5.1 cu. ft.
Number of Ovens
Single
Depth (Without Handles)
71.2 cm
Width
91.1 cm
Weight
178.26 kg
Class Width
36"
Height
91.1 cm
Oven Light
Y
Convection
Y
Fuel Type
Natural Gas
Color
Stainless Steel
Series Name
5 Series
Manufacturer Color
Stainless Steel with Polished Chrome Trim
Installation Type
Freestanding
Programs
Natural Airflow Bake | Convection Bake | Infrared Broil | Convection Infrared Broil | Convection Dehydrate | Convection Defrost
Information
120 VAC / 60 Hz | 4 ft (121.9 cm) power cord | 3-wire cord with grounded 3-prong plug attached to product | 1.5 amp
Additional Dimensions
Overall Width: 35-7/8" (91.1 cm) | Overall Height (from bottom): | Base height to top of side trim: 35-7/8" (91.1 cm) minimum to 37" (94 cm) maximum | Legs adjustment: 1-1/8" (2.9 cm) | Additions to base height: | Island trim: +1" (2.5 cm) | Backguard: +8" (15.2 cm) | High shelf: +23-1/2" (59.7 cm) | Overall Depth from rear: | To end of side panel: 24-5/16" (61.8 cm) | To front of door: 25-3/4" (65.4 cm) | To end of door handle: 28-11/16" (72.9 cm)
Additional Information
Exclusive VSH™ (VariSimmer-to-high) Pro sealed burner system | All other burners rated at 15,000 BTU | Exclusive VariSimmer™ setting for all burners | All burners equipped with SureSpark™ ignition system for consistent and reliable ignition | Automatic re-ignition; burners light at any knob position and re-light if extinguished, even on the lowest setting | Stainless steel knobs and round bezels included as standard | Exclusive combination of single 30,000 BTU U-shaped burner and infrared broiler with SureSpark™ ignition system | Gourmet-Glo™ infrared broiler provides intense searing heat for broiling applications | Large-capacity oven with six rack positions | 36" model accommodates a full-size commercial sheet pan | All convection modes use the ProFlow™ convection air baffle for balanced airflow and even heat distribution | Exclusive Gentle Close™ door allows slow and quiet closing | Convection fan switch conveniently located on the control panel | Two halogen oven lights for excellent visibility throughout the oven cavity
Technologies
VSH™ (VariSimmer-to-high) Pro | VariSimmer™ Setting | Gourmet-Glo™ Gas Infrared Broiler | ProFlow™ Convection Air Baffle | SureSpark™ Ignition System
Appliance Care
Exclusive one-piece tooled and porcelainized cooking surface for easy cleanup | Removable burner caps for quick cleaning | Heavy-duty porcelainized cast-iron removable grates provide continuous front-to-rear and left-to-right cooking surface for easy movement of large pots
Warranty
2-year full warranty – complete product | 90-day full warranty – cosmetic parts such as glass, painted items, and decorative items | 5-year limited warranty – gas burners
Optional
BG8536SS – 8"H backguard for 36" range | HS24536SS – high shelf for 36" range | P24CSTSS – countertop side trim (2 pieces) | P36CRTSS – countertop rear trim for 36" range | P36CBF4SS – curb base and custom curb base front for 36" range | LPKPDR01 – LP/Propane conversion kit
