This Fisher & Paykel Classic style 30-inch dual-fuel range features 4 burners, convection oven, 9 oven functions and a 3.5 total capacity.
AEROTECH™ TECHNOLOGYAeroTech™ system circulates air evenly throughout the entire oven so dishes on the top shelf turn out just as perfect as food cooking on the bottom shelf.
EASY TO CLEAN - DUAL FUEL / GAS RANGES
The Dual Fuel Range oven has a self-cleaning function and removable side racks. The cooktop has sealed burners and an encapsulated cooking surface with a commercial-style stainless steel finish.
EVEN HEAT
Accurate, electronically-controlled oven heat ensures a great result every time. Dishes on the top shelf turn out as perfectly as the ones on the bottom due to Fisher & Paykel' AeroTech™ convection system that circulates air evenly throughout the entire oven.
BURNER POWER & CONTROL
Instant and immediate control from the highest to the gentlest heat. The finely tuned cooktop controls let you sear, stir fry or simmer a delicate sauce to perfection.
Features
- Oven Light:
Y - Self-Cleaning:
Y - Technologies:
• AeroTech™ Technology
• Aero™ Bake
• Aero™ Broil
• Aero™ Pastry with Pizza Mode
• True Aero™
• True Convection - Additional Information:
• Advanced Cooling System
• Broil: 4050 W
• 7 Rack Positions
• Anti-Tilt Bracket
• Auto Re-Ignition System
• Balanced Oven Door
• Catalytic Venting System
• CoolTouch Door
• Full Extension Telescopic Sliding Shelves
• Non-Tip Shelves
• Automatic Cooking/Minute Timer
• Automatic Pre-Set Temperatures
• Bright Chromed, Cast Zinc Dials with Illuminated Halos
• Celsius/Fahrenheit Temperature
• Electronic Clock
• High Resolution Display
• Laser Etched Graphics
• Precise Electronic Temperature Control
• Turned Stainless Steel Clock Buttons
• Turned Stainless Steel Clock Crown (Dial) - Convection:
Y
Accessories
- Included:
• 2-pc Grill System (Broil Pan and Grill Rack)
• Broil Pan
• Full Extension Telescopic Shelves: 2 Sets (Part 578776)
• Grill Rack
• Pyrolytic-Proof Shelf RunnersL 1 Set
• Small Pot Support: 1 (Part 533981 Cast)
• Wok Stand: 1 (Part 534678) - Optional:
• Hob Rear Trim 3 1/8" (Part 81656)
• Kick Strip, Stainless Steel (Part 81660)
Documents
- Product Sheet (en)
- Dimensions Guide (en)
- Owner's manual (en)
- Installation guide (en)
- Warranty Details (en)
Specifications
Class Width
30"Additional Dimensions
Cutout: Depth 25 1/4", Width 30"Width
75.88 cmDepth (Without Handles)
64.14 cmHeight
90.81 cmBurners
SealedBurners/Elements
4Burners/Elements Output
• Dual Wok Burner Inner / Outer (Natural Gas) X2: 1000 - 18000 BTU
• Max Burner Power: 18000 BTU
• Semi-rapid Burner (LPG) X2: 1500 - 8000 BTU
• Semi-rapid Burner (Natural Gas) X2: 1500 - 8000 BTU
• Total Cooktop Power: 52000 BTUOven Light
YSelf-Cleaning
YTechnologies
• AeroTech™ Technology
• Aero™ Bake
• Aero™ Broil
• Aero™ Pastry with Pizza Mode
• True Aero™
• True ConvectionAdditional Information
• Advanced Cooling System
• Broil: 4050 W
• 7 Rack Positions
• Anti-Tilt Bracket
• Auto Re-Ignition System
• Balanced Oven Door
• Catalytic Venting System
• CoolTouch Door
• Full Extension Telescopic Sliding Shelves
• Non-Tip Shelves
• Automatic Cooking/Minute Timer
• Automatic Pre-Set Temperatures
• Bright Chromed, Cast Zinc Dials with Illuminated Halos
• Celsius/Fahrenheit Temperature
• Electronic Clock
• High Resolution Display
• Laser Etched Graphics
• Precise Electronic Temperature Control
• Turned Stainless Steel Clock Buttons
• Turned Stainless Steel Clock Crown (Dial)Convection
YWarming
YPower
220 WIncluded
• 2-pc Grill System (Broil Pan and Grill Rack)
• Broil Pan
• Full Extension Telescopic Shelves: 2 Sets (Part 578776)
• Grill Rack
• Pyrolytic-Proof Shelf RunnersL 1 Set
• Small Pot Support: 1 (Part 533981 Cast)
• Wok Stand: 1 (Part 534678)Optional
• Hob Rear Trim 3 1/8" (Part 81656)
• Kick Strip, Stainless Steel (Part 81660)Information
• 208 V / 240 V
• 60 Hz
• 30 AWarranty
Limited 2 Years Parts and LaborUPC#
822843813209Appliance Care
Pyrolytic Self-CleanFuel Type
Dual Fuel - Natural GasSeries Name
ClassicManufacturer Color
RedColor
RedInstallation Type
FreestandingPrograms
• Aero™ Bake
• Aero™ Broil
• Aero™ Pastry with Pizza Mode
• Bake
• Maxi Broil
• Rapid Proof
• Roast
• Self-Clean Function
• True Aero™Number of Ovens
SingleCapacity (cu. ft.)
3.5 cu.ft.Sabbath/Star-K
Y
