Cooking zones

• Useable area: 9 7/32" x 15 25/32" (234 x 401 mm).

• Control knobs with illuminated ring.
• Integrated control panel.
• Electronic temperature control from 240(degree)F to 480(degree)F.

• Heating element with 1800 W.
• Keeping warm setting.
• Cleaning setting.
• Stainless steel frame seamlessly welded with the stainless steel surface.

• Pre-heat and residual heat indicator.
• Operation indicator.
• Safety shut-off.

• The distance from the upper edge of the work surface to the upper edge of the intermediate shelf must be at least 6" (150 mm).
• Appliance can be snapped into the countertop from above.
• Above countertop minimum clearance of at least 1 1/4" from adjacent heat-sensitive furniture or contact surfaces must be observed or thermal insulation must be installed.
• Intermediate shelf required; after installation, this shelf must only be removed using tools to guarantee the touch protection from below.
• Appliance weight: approx. 9 kg.

• Total rating: Connected load: 1800 W
• Plan for a 59 1/16" connecting cable
  without plug (hardwire required).

• Can be combined with cooktops of the Vario 200 series to a harmonic unity
• Control panel for comfortable and secure operation
• Japanese traditional cooking, directly on the stainless steel surface
• Exact temperature control up to 480 (degree)F, with warming and cleaning settings
• Keeping warm setting
