Cooking zones
- Useable area: 9 7/32" x 15 25/32" (234 x 401 mm).
- Control knobs with illuminated ring.
- Integrated control panel.
- Electronic temperature control from 240(degree)F to 480(degree)F.
- Heating element with 1800 W.
- Keeping warm setting.
- Cleaning setting.
- Stainless steel frame seamlessly welded with the stainless steel surface.
- Pre-heat and residual heat indicator.
- Operation indicator.
- Safety shut-off.
- The distance from the upper edge of the work surface to the upper edge of the intermediate shelf must be at least 6" (150 mm).
- Appliance can be snapped into the countertop from above.
- Above countertop minimum clearance of at least 1 1/4" from adjacent heat-sensitive furniture or contact surfaces must be observed or thermal insulation must be installed.
- Intermediate shelf required; after installation, this shelf must only be removed using tools to guarantee the touch protection from below.
- Appliance weight: approx. 9 kg.
- Total rating: Connected load: 1800 W
- Plan for a 59 1/16" connecting cable
without plug (hardwire required).
- Can be combined with cooktops of the Vario 200 series to a harmonic unity
- Control panel for comfortable and secure operation
- Japanese traditional cooking, directly on the stainless steel surface
- Exact temperature control up to 480 (degree)F, with warming and cleaning settings
- Keeping warm setting
Specifications
UPC: 825225949428
