Cooking modes

• Convection.
  Economy convection..
  Top + bottom heat.
  Top + 1/3 bottom heat.
  Top heat.
  1/3 top + bottom heat.
  Bottom heat.
  Convection + bottom heat.
  Convection + 1/3 bottom heat.
  Convection broiling..
  Broiling.
  Compact grill.
  Baking stone operation.
  Roaster function.
  Dough proofing.
  Defrosting.
  Keeping warm.

• Rotary knob and TFT touch display operation.
• Clear text display in 44 languages.
• Option to save 50 individual recipes (incl. core temperature probe)
• Personalization of automatic programs.
• Information key with use indicators.
• Front-hinged door with 90(degree) door opening angle.

• Three-point core temperature prove with automatic shut-off and estimation of cooking time.
• Automatic programs.
• Rotisserie spit.
• Baking stone outlet.
• Actual temperature display.
• Fast heating setting.
• 60 W halogen light on the top.
• 2 x 10 W halogen light on the side.
• Enamelled side shelf supports with 3 tray levels, pyrolysis-safe.
• Home network integration for digital services (Home Connect) either via cable connection LAN (recommended) or wireless via WiFi.
• The use of the Home Connect functionality depends on the Home Connect services, which are not available in every country. For further information please check: home-connect.com.

• Thermally insulated door with quintuple glazing.
• Child lock.
• Safety shut-off.
• Cooled housing with temperature protection.

• Pyrolytic self-cleaning.
• Gaggenau Clean-Enamel.
• Heated air cleaning catalyst.

• The door panel surface of the
  appliance extends 1 " (40 mm) from
  the cabinet front.
• The outer edge of the door handle
  extends 3 " (90 mm) from the
  cabinet front.
• For installation underneath cooktops:
  Distance between the underside of the
  cooktop and the top edge of the oven
  cavity: min. 9/16". The
  planning notes for the cooktops
  (particularly regarding ventilation, gas/
  electric connection) must be taken into
  account.
• To achieve the 21 5/8" (550 mm)
  installation depth, the connection
  cable needs to follow the slanted edge
  on the corner of the housing.
• Plan a power outlet outside of the
  cut-out niche.
• The LAN port can be found at the back on the upper left side.

• Total rating 5.9 KW.
• Total Amps: 25 A.
• 208 / 220 - 240 V / 60 Hz.
• Connection cable 47 1/4" without plug.
• Plan for an ethernet cable for distances where the blower is located over 68" (1.75m).

• One-piece front-hinged door with 3 mm precision crafted stainless steel front door panel
• Soft door opening and closing system
• Diagonally positioned light sources for optimal interior lighting
• Pyrolytic self-cleaning system
• Universal heating system with 17 heating methods, with core temperature probe, rotisserie spit and baking stone operation
