Installing this stove hood is quick and easy. The FIT system helps reduce measuring, cutting and trim for a smooth fit. When cooking introduces steam, grease, smoke or odors into the surrounding air, the powerful 2-speed hood vent kitchen fan takes care of it.
FIT SYSTEMThe FIT system eliminates measuring, cutting and filler strips for a perfect fit every time. The FIT system ensures your hood will install seamlessly into your cabinet cutout in three easy steps.
ECONOMY HOOD SOUND LEVELS
Keep the hood from disturbing family time in the kitchen. This hood features the quiet operation of 4.5 sones at the hood's highest speed with 2 fan speeds and a recirculation option. Based on vertical 7" round duct installation.
HIDDEN VENT
This sleek and stylish hidden vent matches almost every modern or traditional kitchen. The design moves the ventilation out of sight to create a seamless look and a surface that's super easy to clean.
INCANDESCENT LIGHTING
Incandescent bulb provide bright cooktop lighting to make preparation easy.
DISHWASHER SAFE GREASE FILTER
Wash metal filter as needed in dishwasher or hot detergent solution.
Features
- Speeds:
2 - Dishwasher-Proof Filters:
Y - Additional Information:
• Sones with High Speed: 5.5 (Vertical)
• 40K BTU Threshold
• Convertible to re-circulating
• Rocker switch
• 75 Watt bulb not included
• FIT System installation
• 3-1/4" x 10" Damper - Ducting Information:
Rectangular
Documents
*While we place great care into preparing product descriptions and prices, sometimes technical and typographical errors or omissions may occur. Appliance Canada cannot be held responsible for such errors and we apologize for any inconvenience this may cause.
Specifications
Style
StandardAirflow
250 CFMManufacturer Color
Stainless SteelColor
Stainless SteelInstallation
Under-CabinetBlower Included
YSpeeds
2Dishwasher-Proof Filters
YAdditional Information
• Sones with High Speed: 5.5 (Vertical)
• 40K BTU Threshold
• Convertible to re-circulating
• Rocker switch
• 75 Watt bulb not included
• FIT System installation
• 3-1/4" x 10" DamperDucting Information
RectangularInformation
• 120 V
• 60 HzWidth
76.04 cmHeight
12.54 cmDepth
47.31 cmWeight
6.35 kgAdditional Dimensions
• 24" (61.0 cm) minimum distance from electric cooking surface
• 24" (61.0 cm) minimum distance from gas cooking surface
• 30" (76.2 cm) suggested maximum above the cooking surface
• 18" (45.7 cm) minimum clearance - upper cabinet to countertop
• 12" (30.5 cm) cabinet depth
• 36" (91.4 cm) base cabinet heightClass Width
30"UPC#
883049326573Weight
7.71 kgWidth
80.65 cmHeight
53.34 cmDepth
17.78 cmWarranty
Limited 1 Year Parts and LaborInformation
ADA
