A quiet storm of air-clearing power in a designer package, the Monsoon Mini II gets the job done. It features a 600-CFM blower, hybrid baffle filters, Airflow Control Technology (ACT™), and dual-level LumiLight LED lighting. Also includes recirculating and make-up air options.

Airflow Control Technology (ACT) allows the installer to set the maximum fan CFM to align with local codes and regulations.

Features

• Ducting Information:• Vertical Internal Blower 7" Round, 3-1/4" x 10"
  • Horizontal Internal Blower 3-1/4" x 10"
• Additional Information:• Blower CFM (Min. - Max.) 290 - 600
  • Sones (Min. - Max.) 1.5 - 6
  • ACT 390 CFM (Min. - Max.) 290 - 390
  • ACT 290 CFM (Min. - Max.) 290 - 290

  • Electronic Touch Controls
  • Auto Delay-Off
  • LumiLight LED, 6W x2
  • Dual-Level Lighting
  • Filters Hybrid Baffle x2
  • Recirculating Option
• Speeds:3 Speeds: *When ACT™ is enabled the maximum speed levels will change. ACT 390 = 2 speeds and ACT 290 = 1 speeds
• Technologies:ACT™ Technology

Accessories

• Optional:• Recirculating Kit ZRC-9100A
  • Make-Up Air Kit MUA006A
  • Damper, 7" Round AK00067

Documents

• Product Sheet (en)
• Dimensions Guide (en)
• Owner's manual (en)
• Installation guide (en)
