About this Product
A premium 30” fully integrated refrigerator designed to blend seamlessly into your cabinetry. With TwinCooling Plus technology, frost-free performance, LED lighting, and smart digital controls, the PC30IFF delivers exceptional food preservation in a beautifully discreet design.
Documents
Specifications
| Manufacturer Color | Panel Ready | Door Hinge | Right | Color | Panel Ready |
| Installation Type | Built-In | Counter-Depth | N | Reversible Doors | Y |
| Refrigerator Type | Bottom Freezer | Interior Light | Y | Door Alarm | Y |
| Frost Free | Y | Control Lock | Y | Digital Display | Y |
| Crisper Drawers | Y | Wi-Fi | N | Additional Freezer Information | No. of Freezer Drawers: 1 Freezer Drawer (2 Compartments) |
| Sabbath Mode | Y | Energy Star Certified | Y | Water System | None |
| Ice System | None | Freezer | 4.5 cu. ft. | Refrigerator | 11.5 cu. ft. |
| Total | 16.0 cu. ft. | Overall Depth | 60.0 cm | Class Height | 70" and More |
| Additional Dimensions | Cut-Out Dimensions (In / mm) (W / H / D): 30" / 84" / 25"–25 5/8" (762 mm / 2134 mm / 635–647 mm) | Class Width | 29" to 31.9" | Width | 75.6 cm |
| Height (With Hinge) | 211.5 cm | Warranty | 2 Years Parts and labor | ||
|
Technologies TwinCooling Plus Technology
| |||||
|
Information Voltage: 120 V | Frequency: 60 Hz | Amperage: 15 A
| |||||
Door Hinge: Right
Specifications
Manufacturer Color
Panel Ready
Door Hinge
Right
Color
Panel Ready
Installation Type
Built-In
Counter-Depth
N
Reversible Doors
Y
Refrigerator Type
Bottom Freezer
Interior Light
Y
Door Alarm
Y
Frost Free
Y
Control Lock
Y
Digital Display
Y
Crisper Drawers
Y
Wi-Fi
N
Additional Freezer Information
No. of Freezer Drawers: 1 Freezer Drawer (2 Compartments)
Sabbath Mode
Y
Energy Star Certified
Y
Water System
None
Ice System
None
Freezer
4.5 cu. ft.
Refrigerator
11.5 cu. ft.
Total
16.0 cu. ft.
Overall Depth
60.0 cm
Class Height
70" and More
Class Width
29" to 31.9"
Width
75.6 cm
Height (With Hinge)
211.5 cm
Warranty
2 Years Parts and labor
Technologies
TwinCooling Plus Technology
Additional Information
Fully Integrated Panel-Ready Design — Disappears into your cabinetry for a premium built-in look. | TwinCooling Plus Technology — Independent cooling systems prevent odor transfer and preserve freshness. | Total No Frost — Consistent temperatures with zero maintenance. | Digital LED Touch Control Interface — Intuitive, elegant, and easy to use. | LED Interior Lighting — Beautiful, bright illumination from all angles. | Fresh Zone Preservation Drawer — Helps ingredients stay fresh and full of flavor. | Spill-Safe Glass Shelves — Durable, easy-to-clean shelving. | Reversible Door Swing — Flexible installation options. | Display Functions: Refrigerator / Freezer Temperature, Fresh Food Compartment, Holiday Mode, Sabbath Mode, Eco Mode, Child Lock | Door Open Alarm: Yes | Display Type: Digital Touch Control Display | Interior Lighting: LED (Side Walls, Ceiling) | No. of Compressors: 1 Variable Speed with Inverter (VCC) | No. of Adjustable Shelves: 3 Glass Shelves (1 Fixed, 2 Adjustable) | Spill Safe Shelves: Yes | No. of Humidity Controlled Crispers: 1 | No. of Fresh Zone Preservation Drawers: 1 | No. of Door Bins: 3 (2 + 1 Gallon Rack) | Fan Assisted Cooling
Additional Dimensions
Cut-Out Dimensions (In / mm) (W / H / D): 30" / 84" / 25"–25 5/8" (762 mm / 2134 mm / 635–647 mm)
Information
Voltage: 120 V | Frequency: 60 Hz | Amperage: 15 A
